3500 Kgs Diesel Forklift 3.5 Ton Bale Clamp Chinese Engine Counterbalance

Ask Lasest Price
Brand Name :	YEAWEY
Model Number :	CPCD35
Certification :	CE ISO，SGS
Price :	6000-7500 usd
Payment Terms :	L/C, T/T, D/P, D/A, Western Union, MoneyGram
Supply Ability :	100 units per month
Delivery Time :	5-8 working days

Add to Cart

Product Details
Company Profile

3500 Kgs Diesel Forklift 3.5 Ton Bale Clamp Chinese Engine Counterbalance

3500 kgs 3.5 Ton new diesel forklift truck bale clamp Chinese engine

Main information:

Product name: 3.5Ton diesel counter balance forklift

Engine: XINCHAI C490BPG

Transmission: Mechanical

Mast type: 2 stage mast 4m lifting height

Tires: pneumatic

Fork: 1220mm

Attachments: according to customer's requirements.

The higher-end model in of YEAWEY forklift products line, sets new bar in counter balance forklifts. It offers graceful appearance and over 55 improvements of inside and out ergonomic design, enhanced safety and performance while lowering vibration, operating noise and easy to maintain.

Working efficiency improved

Small turning radius makes steering flexible and easy.The truck has fast lifting speed, good gradeability and high efficiency.High working efficiency guarantees the truck could meet the requirements for various kinds of complicated work condition perfectly wherever at port, dock and railway station.

Ergonomic comfort

Perfect shape & position of manual gear level facilitate the drivers’ operation.Independent dual rear lights together with warning light are easy to recognize & maintain.

Long working life

I beam rails and heavy tie bar construction reduce twisting while handling long,lateral loads on rough surface applications. Sealed bearing load rollers and are externally adjustable to compensate for long term wear.

Steer Axle

Oscillating steer axle allows either wheel to step over obstacles keeping the machine and load level. Flirtation drive& steer tires provide excellent traction and stability.The steering angle is from 54° to 78'with very small turning radius.

Delivery time:
As a factory, we can offer fast products delivery, standard forklift is 7 working days, Forklift with options is 10-20 working days.

Specification			CPCD35
1	Fuel model		Diesel
2	Load capacity	kg	3500
3	Load center	mm	500
4	Lift height	mm	4000
5	Full free lift height	mm	100
6	Fork dimension	mm	1220×125×50
7	Mast tilting angle	Deg.	6/12
8	Min.turning radius	mm	2550
9	Groud clearance	mm	135
10	Overhead guard height	mm	2165
11	Front overhang	mm	495
12	Max travel speed	km/h	19
13	Max lift speed	mm/s	480
14	Max.traction power	KN	13.5
15	Max. gradeability	%	20
16	Total length with fork	mm	4065
17	Total length without fork	mm	2995
18	Total width	mm	1225
19	Mast extended height	mm	4265
20	Mast lowered height	mm	2060
21	Tyres Front		28x9-15-12PR
22	Type Rear		6.50-10-10PR
23	Wheelbase	mm	1700
24	Tread	mm	1000/970
25	Service weight	Kg	4800
26	Battery	V/Ah	12/80
27	Engine model		Xinchai A495 engine 42 kw
28	Engine power	kw/r.p.m	42
29	Transmission		Mechanical or Automatic
30	Work press	Mpa	18.5
