CQDE15 48V 1.5T Electric Reach Truck 1500kg Seat Type Triplex 3m-12m Mast

Ask Lasest Price
Brand Name :	YEAWEY
Model Number :	CQDE15
Certification :	CE ISO，SGS
Price :	6000-7500 usd
Payment Terms :	L/C, T/T, D/P, D/A, Western Union, MoneyGram
Supply Ability :	100 units per month
Delivery Time :	5-8 working days

Add to Cart

Product Details
Company Profile

CQDE15 48V 1.5T Electric Reach Truck 1500kg Seat Type Triplex 3m-12m Mast

1500kg CQDE15 48V 1.5T Electric Reach forklift truck seat type triplex 3-12m mast

Main information:

Curtis AC controller

AC lift and drive motor

Lift height 3m to 6m

Lead acid battery 48V/400AH

Seat type

The YEAWEY Lead acid / Lithium battery stand reach truck adopts four columns for cabin to penetrate the frame which is both beautiful and safe.Wide field of vision and driving space along with high elastic shock-absorbing seats provide a unique driving pleasure.

Multi-function LCD instrument

Multi-function LCD instrument can display steering wheel position, battery power, power alarm, fault code running time, driving speed and other information.

Superior pump and controller

Low-noise gear hydraulic pump reduces the lifting noise of the whole vehicle.Travel motor controllers, hydraulic pump motor controllers and steering motor controllers of international well-known brands are self-protected, maintenance free and have superior performance.

Suspension seat(optional)

The highly elastic shock-absorbing seat greatly reduces the transmission of vibration to the driver. the seat can be adjusted in multiple positions to meet the operation needs.

Item	Model		CQDE15-45S
1	Power type		Electric
2	Drive mode		Seated
3	Load capacity	Q(kg)	1500
4	Load center	C(mm)	500
5	Front overhang	X(mm)	183
6	Wheel base	Y(mm)	1470
7	Reach distance	L(mm)	505
8	Self weight with battery	kg	3000
9	Tire type		Pu solid tire
10	Front tire size	∅×w(mm)	267*114
11	Rear tire size	∅×w(mm)	382*142
12	Track width, front wheels	b10(mm)	1180
13	Height-Mast Lowered	h1(mm)	2105
14	Free Lift Height	h2(mm)	1500
15	Lift Height	h3(mm)	4500
16	The maximum height of the gantry during homework	h4(mm)	5465
17	The height of overhead guards	h14(mm)	2180
18	The height when fork lowered	h13(mm)	35
19	Tilt-Forward/Back	α/β(°)	3/5
20	Overall length(with forks)	l2(mm)	2477
21	Width of the body	b1(mm)	1270
22	Fork Dimensions	s/e/l(mm)	35/100/1070
23	Fork Spread	b5(mm)	210-705
24	Min ground clearance	m2(mm)	70
25	Aisle Width,pallet 1000*1200mm	Ast(mm)	2964
26	Min. Turning radius	Wa(mm)	1800
27	Max travel speed unladen/Load	km/h	7.8/6.8
28	Max. lifting speed unladen/Load	m/s	0.330/0.245
29	Max. lowing speed unladen/Load	m/s	0.260/0.325
30	Grade Ability unladen/Load	％	≤10
31	Drive brake		electromagnetic
32	Drive motor	kw	6.5
33	Lift motor	kw	6.3
34	Battery type		Lead acid
35	Battery capacity	V/Ah	48V300Ah
36	Charger	V/A	48V/40A
37	DriveControllingType		alternating current
38	The noise level in the driver's ear according to EN12053	dB(A)	75

CQDE15 48V 1.5T Electric Reach Truck 1500kg Seat Type Triplex 3m-12m Mast
